A PERFECT FIT FOR EVERY USER
HumanSport is so simple, intuitive and natural that it feels as if it were custom-built for each and every user. Seven cable-based machines with dual weight stacks provide a complete range of workouts for total body training. When paired with the provided programming designed by our Master Instructors, HumanSport makes a powerful addition to any facility.
W: 58 in (147 cm)
L: 58 in (147 cm)
H: 83 in (211 cm)
STACK WEIGHT2x 88 lbs (2x 40 kg)
OVERALL WEIGHT: 655 lbs (298 kg)
SHIPPING WEIGHT: 772 lbs (351 kg)
*Frames colors 13, 25, 26 and 60 and carbon fiber trim are available at no cost but longer lead times apply, varies by region.
| WIDTH | 58 in (147 cm) |
|---|---|
| LENGTH | 58 in (147 cm) |
| HEIGHT | 83 in (211 cm) |
| STACK WEIGHT | 2x 88 lbs (2x 40 kg) |
| OVERALL WEIGHT | 655 lbs (298 kg) |
| SHIPPING WEIGHT | 772 lbs (351 kg) |
| USER DEFINED RANGE OF MOTION | Yes, multiple pulling motions including frontal plane and sagittal plane pull, rotational pull and unilateral pull. Drop-down seat for enhanced training options in the standing position. Seated stable, seated unstable and standing positions can be utilized |
|---|---|
| ASSISTED ADJUSTMENTS | No but knee pad adjustment stabilizes users lifting heavy loads |
| COLOR CODED PIVOT POINTS AND ADJUSTMENTS | Yes |
| UNILATERAL OR BILATERAL MOVEMENT | Yes, Unilateral or bilateral use user defined |
| CONVERGING OR DIVERGING MOVEMENTS | Yes, user defined |
| PULLEY RATIO | 2:1 ratio |
| TOTAL STACK WEIGHT | Stack Weight Capacity: 2x 88 lbs (2x 40 kg) |
|---|---|
| INCREMENTAL WEIGHT SYSTEM | No |
| WEIGHT STACK TOWER HEIGHT | 65 in (165 cm) |
| PLATE LOADED | N/A |
| WEIGHT STORAGE SOLUTION | N/A |
| LNL TECHNOLOGY | Yes, standard |
| ADD-ON RESISTANCE AVAILABLE | No |
| WEIGHT STACK SHROUD SPECIFICATIONS | Inside and outside steel shrouds. |
| STANDARD FRAME COLOR OPTIONS | Silver with wood trim, Black with carbon fiber trim |
|---|---|
| STANDARD UPHOLSTERY COLOR OPTIONS | Black |
| FRAME FINISH | Electrostatic Powder coating |
| CUSTOMIZABLE PAINT OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CUSTOMIZABLE UPHOLSTERY OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CUSTOMIZABLE BRANDING OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CABLE VS. BELT DRIVEN TRANSMISSION | 3mm cable driven |
| BOLT DOWN LOCATIONS DEFINED | Yes |
| INTEGRATED LEVELING SYSTEM | No, rubber feet for floor protection |
| HARDWARE TYPE | Hex / Button Head |
| TUBBING STYLE & THICKNESS | Modern blend of square and round tubing. Most are 3 or 2.5 mm / 11 ga |
| STATIC PLACARDS | Start finish diagram |
|---|---|
| MULTI-LANGUAGE PLACARDS OPTIONS AVAILABLE | Yes |
| ANIMATED LENTICULAR | No |
| SAFETY CATCH & STOPS | No |
| WATER BOTTLE HOLDER | No |
| PHONE HOLDER | No |
| GRIP SPECIFICATIONS | Multiple accessory handle configurations with multiple D-rings to support varying levels of pre-stretch and modalities |
| FOOT PLATFORM | N/A |
| CONTOURED PADS | Yes |
| RESTRAINT SYSTEM | Inside and outside steel shrouds. |
