Proven. Smart.
Effective.
The Impact® Strength line brings many subtle innovations to the power of your next weight training workout. It is the evolution of the proven biomechanics and user features that have made the strength line a solid, competitive product. This line retains all the unique, proven, individual design features that customers have stated are ideal such as pre-stretch, start assist, range of motion selection and graduated & standard heavy weight stacks. Impact Strength incorporates new aesthetics and biomechanics features that have established its position as a competitive and diverse strength product line.
W: 47 IN (119 CM)
L: 74 IN (187 CM)
H: 65 IN (165 CM)
STACK WEIGHT: 360 LBS (180 KG)
OVERALL WEIGHT: 968 LBS (439 KG)
SHIPPING WEIGHT: 1078 LBS (489 KG)
*Frames colors 19, 25, 26, and 60 are available at no cost but longer lead times apply, varies by region.
| W | 47 IN (119 CM) |
|---|---|
| L | 74 IN (187 CM) |
| H | 65 IN (165 CM) |
| STACK WEIGHT | 360 LBS (180 KG) |
| OVERALL WEIGHT | 968 LBS (439 KG) |
| SHIPPING WEIGHT | 1078 LBS (489 KG) |
| USER DEFINED RANGE OF MOTION | Fixed path |
|---|---|
| ASSISTED ADJUSTMENTS | Gravity assisted seat bottom |
| COLOR CODED PIVOT POINTS AND ADJUSTMENTS | Yes on all units |
| UNILATERAL OR BILATERAL MOVEMENT | Possible if user uses one handle at a time |
| CONVERGING OR DIVERGING MOVEMENTS | Linear motion |
| PULLEY RATIO | 1:1 |
| TOTAL STACK WEIGHT | 190 LB (86 KG) |
|---|---|
| INCREMENTAL WEIGHT SYSTEM | 5/10/15, 190 |
| WEIGHT STACK TOWER HEIGHT | 54.5 in (138 cm) |
| PLATE LOADED | N/A |
| WEIGHT STORAGE SOLUTION | N/A |
| LNL TECHNOLOGY | Yes |
| ADD-ON RESISTANCE AVAILABLE | No |
| WEIGHT STACK SHROUD SPECIFICATIONS | Transparent, smoked plexiglass inside and outside shrouds |
Selecting a weight with the intuitive Lock N Load design is as easy as flicking a switch. Universally color coded switches engage and disengage the weight via an internal pin, providing a safer, more durable and maintenance free operation. Lock N Load prevents unnecessary maintenance headaches since there are no pins to lose or replace.
This 23 piece line covers all of the essentials needed make up the foundation of any facility. Suited for all fitness levels, users can isolate and focus on each body part, making their workout customizable and efficient. Proven biomechanics and a rock solid construction ensure the durability that club owners expect.
| STANDARD FRAME COLOR OPTIONS | Silver, White, Black |
|---|---|
| STANDARD UPHOLSTERY COLOR OPTIONS | Black |
| FRAME FINISH | Electrostatic Powder coating |
| CUSTOMIZABLE PAINT OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CUSTOMIZABLE UPHOLSTERY OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CUSTOMIZABLE BRANDING OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CABLE VS. BELT DRIVEN TRANSMISSION | SKU dependent |
| BOLT DOWN LOCATIONS DEFINED | Yes |
| INTEGRATED LEVELING SYSTEM | No, rubber feet for floor protection |
| HARDWARE TYPE | Hex / Button Head |
| TUBBING STYLE & THICKNESS | Modern blend of square and round tubing. Most are 3 or 2.5mm / 11 ga |
| HEIGHT | Changes per unit yet mostly 60" |
| STATIC PLACARDS | Yes, simple and intuitive placard |
|---|---|
| MULTI-LANGUAGE PLACARDS OPTIONS AVAILABLE | Yes |
| ANIMATED LENTICULAR | No |
| SAFETY CATCH & STOPS | Yes, SKU dependent |
| WATER BOTTLE HOLDER | No |
| PHONE HOLDER | No |
| GRIP SPECIFICATIONS | Rubber, large grips for pushing, smaller grips for pulling. |
| FOOT PLATFORM | Machine dependent |
| CONTOURED PADS | Yes, contoured back pads on select machines |
| BELT STABILIZATION SYSTEM | No |
