Working out with plates is one of the most effective ways to train, which is why plate loaded machines are a staple for facilities. Whether you are looking to build a full strength circuit or round out your offering with specific pieces, Nautilus Plate Loaded offers the best machines for plate workouts. Each machine is built strong enough to stand up to full commercial use and is designed to make plate workouts as effective, rewarding and safe as possible.
W: 34 IN (86 CM)
L: 72 IN (183 CM)
H: 49 IN (124 CM)
STACK WEIGHT: N/A
OVERALL WEIGHT: 214 LBS (97 KG)
SHIPPING WEIGHT: 252 LBS (114 KG)
*Frames colors 19, 25, 26, and 60 are available at no cost but longer lead times apply, varies by region.
| USER DEFINED RANGE OF MOTION | Yes with two hand grip positions for workout variation |
|---|---|
| ASSISTED ADJUSTMENTS | No |
| COLOR CODED PIVOT POINTS AND ADJUSTMENTS | N/A |
| UNILATERAL OR BILATERAL MOVEMENT | N/A |
| CONVERGING OR DIVERGING MOVEMENTS | N/A |
| PULLEY RATIO | N/A |
| W | 34 IN (86 CM) |
|---|---|
| L | 72 IN (183 CM) |
| H | 49 IN (124 CM) |
| STACK WEIGHT | N/A |
| OVERALL WEIGHT | 214 LBS (97 KG) |
| SHIPPING WEIGHT | 252 LBS (114 KG) |
| TOTAL STACK WEIGHT | N/A |
|---|---|
| INCREMENTAL WEIGHT SYSTEM | N/A |
| WEIGHT STACK TOWER HEIGHT | N/A |
| PLATE LOADED | 35 lb (15.8 kg) starting resistance |
| WEIGHT STORAGE SOLUTION | N/A |
| LNL TECHNOLOGY | N/A |
| ADD-ON RESISTANCE AVAILABLE | 315 lb (142 kg) max load capacity |
| WEIGHT STACK SHROUD SPECIFICATIONS | N/A |
| STANDARD FRAME COLOR OPTIONS | Silver, White, Black |
|---|---|
| STANDARD UPHOLSTERY COLOR OPTIONS | Black |
| FRAME FINISH | Electrostatic Powder coating |
| CUSTOMIZABLE PAINT OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CUSTOMIZABLE UPHOLSTERY OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CUSTOMIZABLE BRANDING OPTIONS AVAILABLE | N/A |
| CABLE VS. BELT DRIVEN TRANSMISSION | N/A |
| BOLT DOWN LOCATIONS DEFINED | Yes |
| INTEGRATED LEVELING SYSTEM | No, rubber feet for floor protection |
| HARDWARE TYPE | Hex / Button Head |
| TUBBING STYLE & THICKNESS | Modern blend of square and round tubing. Most are 3 or 2.5mm / 11 ga |
| STATIC PLACARDS | Yes |
|---|---|
| MULTI-LANGUAGE PLACARDS OPTIONS AVAILABLE | Yes |
| ANIMATED LENTICULAR | No |
| SAFETY CATCH & STOPS | Easy to reach and operate safety stops with low load points for safe and simple use |
| WATER BOTTLE HOLDER | No |
| PHONE HOLDER | No |
| GRIP SPECIFICATIONS | Rubber, smaller grips. |
| FOOT PLATFORM | Yes, wear guards on step up legs to protect finish |
| CONTOURED PADS | No |
| BELT STABILIZATION SYSTEM | N/A |
