A STRONGER FIRST IMPRESSION
The Nautilus Inspiration Strength® line delivers a series of must have updates to an outstanding strength circuit. Redesigned with beautiful, modern aesthetics and uniform towers, Nautilus Inspiration makes a powerful first impression. Each machine captures the essence of natural human movement. Members will appreciate the many easy to use and easy to see features like the wrap around assisted seat adjustment, Lenticular image placards, pre-stretch and range of motion controls designed to enhance each user’s experience.
W: 58 IN (147 CM)
L: 46 IN (117 CM)
H: 80 IN (203 CM)
STACK WEIGHT: 240 LB (109 KG)
OVERALL WEIGHT: 706 LB (320 KG)
SHIPPING WEIGHT: 798 LB (362 KG)
*Frames colors 13, 25, 26, and 60 are available at no cost but longer lead times apply, varies by region.
“Lock N Load®
Now weight selection is as easy as flipping a switch. The intuitive Lock N Load® design is easily recognizable. If you’ve ever flicked a light switch on and off, you’ll immediately understand how it works. Universally color coded switches engage and disengage the weight via an internal pin, providing a safer, more durable and maintenance free operation. Lock N Load prevents unnecessary maintenance and customer service headaches since there are no pins to lose or replace. “
| W | 58 IN (147 CM) |
|---|---|
| L | 46 IN (117 CM) |
| H | 80 IN (203 CM) |
| STACK WEIGHT | 240 LB (109 KG) |
| OVERALL WEIGHT | 706 LB (320 KG) |
| SHIPPING WEIGHT | 798 LB (362 KG) |
| USER DEFINED RANGE OF MOTION | Fixed path of motion with dual exercise option for Pectoral Fly and Rear Deltoids and standard supinated and pronated grip options |
|---|---|
| ASSISTED ADJUSTMENTS | Wrap-around gas assist seat adjust |
| COLOR CODED PIVOT POINTS AND ADJUSTMENTS | Yes on all units |
| UNILATERAL OR BILATERAL MOVEMENT | Unilateral and Bilateral dependent can be performed (one or two arm movements) |
| CONVERGING OR DIVERGING MOVEMENTS | N/A |
| PULLEY RATIO | 1:1 pulley ratio |
| TOTAL STACK WEIGHT | 240 LB (109 KG) |
|---|---|
| INCREMENTAL WEIGHT SYSTEM | 10 lb increment, 5 lb add on |
| WEIGHT STACK TOWER HEIGHT | Standard 64in (163 cm) height on all products |
| PLATE LOADED | N/A |
| WEIGHT STORAGE SOLUTION | N/A |
| LNL TECHNOLOGY | Yes |
| ADD-ON RESISTANCE AVAILABLE | Yes, 5 lb incremental add on plate |
| WEIGHT STACK SHROUD SPECIFICATIONS | Uniform size, standard steel / customized aluminum materials |
Selecting a weight with the intuitive Lock N Load design is as easy as flicking a switch. Universally color coded switches engage and disengage the weight via an internal pin, providing a safer, more durable and maintenance free operation. Lock N Load prevents unnecessary maintenance headaches since there are no pins to lose or replace.
The beautifully designed Nautilus Inspiration line, with their uniform 64" (163 cm) towers, deliver superior lines of site across your venue and create a visually powerful impression during facility tours. The tower housing is designed to accommodate custom graphics and wraps to personalize the equipment in your facility.
| STANDARD FRAME COLOR OPTIONS | Silver, White, Black |
|---|---|
| STANDARD UPHOLSTERY COLOR OPTIONS | Black |
| FRAME FINISH | Electrostatic Powder coating |
| CUSTOMIZABLE PAINT OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CUSTOMIZABLE UPHOLSTERY OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CUSTOMIZABLE BRANDING OPTIONS AVAILABLE | Yes with additional fees and extended lead times |
| CABLE VS. BELT DRIVEN TRANSMISSION | Cable drive |
| BOLT DOWN LOCATIONS DEFINED | Yes |
| INTEGRATED LEVELING SYSTEM | Yes |
| HARDWARE TYPE | Hex / Button Head |
| TUBBING STYLE & THICKNESS | Modern blend of square and round tubing. Most are 3 or 2.5mm / 11 ga |
| STATIC PLACARDS | Animated lenticulars, showing start and stop positions |
|---|---|
| MULTI-LANGUAGE PLACARDS OPTIONS AVAILABLE | Yes |
| ANIMATED LENTICULAR | Animated lenticulars, showing start and stop positions |
| SAFETY CATCH & STOPS | Yes, end range of motion safety stop |
| WATER BOTTLE HOLDER | Yes, integrated to weight stack tower, eye level |
| PHONE HOLDER | Yes, adjustable in size and position |
| GRIP SPECIFICATIONS | Rubber, large grips for pushing, smaller grips for pulling. |
| FOOT PLATFORM | N/A |
| CONTOURED PADS | Yes, contoured pads |
| BELT STABILIZATION SYSTEM | Yes, heavy-duty seat belt restraint system to accommodate all users |
